2-1/2 Swivel Caster

Description

Description

• 2.5″ heavy duty black rubber tire
• Ball bearing swivel assembly
• Heavy duty steel mounting plate
• Load capacity: 55kg/120lbs
• Mounting plate size: 2.76″ x 3.86″

Spec

MFG Item No: 511-5299854

Material: Steel / Rubber

Color/Finish: Soft Rubber

Size: Medium

Width: 3.90in [99.1mm]

Height: 3.16in [80.3mm]

Depth: 2.76in [70.1mm]

Weight: 0.97Lbs [0.4kg]

Load Capacity: 120.00Lbs [54.4kg]

Caster Wheel Diameter: 2.5 x 1.13in

Caster Wheel Diameter: 2.76 x 3.86in

Country of Origin: Korea

Documents PDF DrawingDXF File3D CAD Link
